ENVIRONMENTAL PUMPS

A RANGE SUITABLE FOR MULTIPLE APPLICATIONS IN THE INDUSTRY

Pumps used for environmental monitoring and sampling need to be tolerable to the various environments they are put in. At BlueDiamond our in house R&D team has developed pioneering ways to pump corrosive and harmful gases without damaging the pump. Through developing different material composites and vigour's testing, BlueDiamond has been able to create a range of pumps specifically dedicated to applications such as environmental monitoring, particle sampling, air pollution monitors and corrosive gas analysers.

DIAPHRAGM PUMPS

The major advantage of the diaphragm pump is that the pumping chamber is totally sealed and, therefore, does not require a sliding seal between moving parts. Vacuum and pressure are produced by the flexing of the diaphragm back and forth in the chamber.

WHY CHOOSE DIAPHRAGM TECHNOLOGY?

• Contamination free pumping.

• Long life, continuous duty.

• Low maintenance.

• Chemical resistant options.

• Pressure / vacuum from the same unit.

RANGE OVERVIEW

FLOW

3.0-34.0 L/Min

VACUUM

Down to 350 MBAR ABS

PRESSURE

Up to 2.2 BAR

D3 DC

• Max Flow : 3.0 l/min

• Max Vacuum : 350 mbar

• Max Pressure : 2.0 bar

• Size : 74 x 29 x 52mm

• Connector Size : 4mm

DATASHEET

FEATURES

Diaphragm : EPDM

Head : NYLON

• POLYPROPYLENE

• PTFE

• 12V • BLDC

• 24V

MATERIALS

PERFORMANCE

( CLICK ON THE GRAPH TO MAGNIFY )

D5 SE / D6 SE

PERFORMANCE

( CLICK ON THE GRAPH TO MAGNIFY )

Diaphragm : EPDM

Head : NYLON

• POLYPROPYLENE

• PTFE

• 12V •110V

• 24V •230V

• BLDC

MATERIALS

• Max Flow : 6.0 l/min

• Max Vacuum : 190 mbar

• Max Pressure : 2.0 bar

• Size : 94 x 80 x 46mm

• Connector Size : 6mm

DATASHEET

FEATURES

D7 SE

PERFORMANCE

( CLICK ON THE GRAPH TO MAGNIFY )

Diaphragm : EPDM

Head : NYLON

• POLYPROPYLENE

• STAINLESS STEEL

•110V • 50/60 Hz

•230V

MATERIALS

• Max Flow : 14.0 l/min

• Max Vacuum : 240 mbar

• Max Pressure : 1.8 bar

• Size : 128 x 94 x 128mm

• Connector Size : 8.0 ,6.4, 6.0

DATASHEET

FEATURES

D7 DE

PERFORMANCE

( CLICK ON THE GRAPH TO MAGNIFY )

Diaphragm : EPDM

Head : NYLON

• POLYPROPYLENE

• STAINLESS STEEL

•110V • 50/60 Hz

•230V

MATERIALS

• Max Flow : 26.0 l/min

• Max Vacuum : 240 mbar

• Max Pressure : 1.8 bar

• Size : 164 x 94 x 128mm

• Connector Size : 8.0 ,6.4, 6.0

DATASHEET

FEATURES

D16

PERFORMANCE

( CLICK ON THE GRAPH TO MAGNIFY )

Diaphragm : SARLINK

Head : NYLON

•110V • 12V

•230V

MATERIALS

• Max Flow : 16.0 l/min

• Max Vacuum : 250 mbar

• Size : 100 x 43 x 71mm

• Connector Size : 10mm

DATASHEET

FEATURES

D34

PERFORMANCE

( CLICK ON THE GRAPH TO MAGNIFY )

Diaphragm : EPDM

Head : NYLON

• 12V

MATERIALS

• Max Flow : 34.0 l/min

• Max Vacuum : 250 mbar

• Size : 141 x 65 x 101mm

• Connector Size : 1/8 NPT

DATASHEET

FEATURES

D16 DUPLEX

PERFORMANCE

( CLICK ON THE GRAPH TO MAGNIFY )

Diaphragm : EPDM

Head : NYLON

• 12V •BLDC

• 24V

MATERIALS

• Max Flow : 24.0 l/min

• Max Vacuum : 250 mbar

• Size : 99 x 114 x 43mm

• Connector Size : 10mm x2

DATASHEET

FEATURES

CAPEX L2

PERFORMANCE

( CLICK ON THE GRAPH TO MAGNIFY )

Diaphragm : EPDM

Head : NYLON

• STAINLESS STEEL

• PP/PTFE

•12V • BLDC

•24V

MATERIALS

• Max Flow : 8.0 l/min

• Max Vacuum : 280 mbar

• Max Pressure : 2.0 bar

• Size : 232 x 178 x 155mm

• Connector Size : 8.0 ,6.4, 6.0

DATASHEET

FEATURES

CAPEX V2 SE

PERFORMANCE

( CLICK ON THE GRAPH TO MAGNIFY )

Diaphragm : EPDM

Head : NYLON

• POLYPROPYLENE

• PP/PTFE

•12V • BLDC

•24V

MATERIALS

• Max Flow : 17.0 l/min

• Max Vacuum : 240 mbar

• Max Pressure : 2.2 bar

• Size : 140 x 67 x 127mm

• Connector Size : 8.0 ,6.4, 6.0

DATASHEET

FEATURES

CAPEX V2 DE

PERFORMANCE

( CLICK ON THE GRAPH TO MAGNIFY )

Diaphragm : EPDM

Head : NYLON

• POLYPROPYLENE

• PP/PTFE

•12V • BLDC

•24V

MATERIALS

• Max Flow : 32.0 l/min

• Max Vacuum : 240 mbar

• Max Pressure : 2.2 bar

• Size : 140 x 67 x 127mm

• Connector Size : 8.0 ,6.4, 6.0

DATASHEET

FEATURES

ENVIRONMENTAL CASE STUDIES

ROTARY DIAPHRAGM PUMPS

The patented rotary diaphragm technology has a revolutionary pumping principle. The flow is initiated by an eccentrically mounted bearing on a drive shaft which revolves within a flexible diaphragm. As the shaft rotates, the bearing flexes the diaphragm, squeezing liquid through the pump.

WHY CHOOSE ROTARY DIAPHRAGM TECHNOLOGY?

• Patented Charles Austen Pumps technology.

• Compact design.

• High vacuum capability.

• No valves, non-clogging.

• AC or DC motor option available.

RANGE OVERVIEW

FLOW

0.24 - 5.0 L/Min

VACUUM

Down to 300 MBAR ABS

PRESSURE

Up to 2 BAR

RD01

PERFORMANCE

( CLICK ON THE GRAPH TO MAGNIFY )

Diaphragm : SARLINK

Head : POLYPROPYLENE

• 110V • 50/60Hz

• 230V

MATERIALS

• Max Flow : 0.14 l/min

• Max Lift : 5.0m

• Max Head : 8.0m

• Size : 87 x 54 x 66mm

• Connector Size : 8mm OD

DATASHEET

FEATURES

RD1

PERFORMANCE

( CLICK ON THE GRAPH TO MAGNIFY )

Diaphragm : SANTROPENE

Head : POLYPROPYLENE

• 12V • BLDC

• 24V

MATERIALS

• Max Flow : 0.85 l/min

• Max Vacuum : 300 mbar

• Max Pressure : 2.0 bar

• Size : 45 x 125 x 61mm

• Connector Size : 8mm OD

DATASHEET

FEATURES

RD2

PERFORMANCE

( CLICK ON THE GRAPH TO MAGNIFY )

Diaphragm : SANTROPENE

Head : POLYPROPYLENE

• 12V • BLDC

• 24V

MATERIALS

• Max Flow : 1.7 l/min

• Max Vacuum : 200 mbar

• Max Pressure : 2.0 bar

• Size : 97 x 77 x 59mm

• Connector Size : 15/8mm OD

DATASHEET

FEATURES

RD3

PERFORMANCE

( CLICK ON THE GRAPH TO MAGNIFY )

Diaphragm : SANTROPENE

Head : POLYPROPYLENE

• 12V • BLDC

• 24V

MATERIALS

• Max Flow : 3.0 l/min

• Max Vacuum : 200 mbar

• Max Pressure : 2.0 bar

• Size : 97 x 77 x 59mm

• Connector Size : 15/8mm OD

DATASHEET

FEATURES

RD5

PERFORMANCE

( CLICK ON THE GRAPH TO MAGNIFY )

Diaphragm : SANTROPENE

Head : POLYPROPYLENE

• 12V • BLDC

• 24V

MATERIALS

• Max Flow : 5.0 l/min

• Max Vacuum : 200 mbar

• Max Pressure : 2.0 bar

• Size : 97 x 77 x 59mm

• Connector Size : 15/8mm OD

DATASHEET

FEATURES

ENVIRONMENTAL CASE STUDIES

LINEAR DIAPHRAGM PUMPS

The simple yet efficient pumping principle uses a magnetically operated diaphragm. This action flexes a diaphragm at one, or both ends of the connecting rod within a totally sealed pumping chamber. This eliminates sliding parts keeping wear, tear and power consumption to a minimum.

WHY CHOOSE LINEAR DIAPHRAGM TECHNOLOGY?

• Exceptionally long life.

• Continuous duty.

• Whisper quiet, minimal vibration.

• Low power consumption.

• Maintenance free.

RANGE OVERVIEW

FLOW

8.0 - 68.0 L/Min

VACUUM

Down to 880 MBAR ABS

PRESSURE

Up to 0.3 BAR

ENQUIRE ABOUT THIS PUMP

LD10

PERFORMANCE

( CLICK ON THE GRAPH TO MAGNIFY )

Diaphragm : EPDM

•110V •12V

•230V

MATERIALS

• Max Flow : 10.0 l/min

• Max Vacuum : 880 mbar

• Max Pressure : 0.2 bar

• Size : 97 x 77 x 59mm

DATASHEET
